1236
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
547 RESET TIMER/
COUNTER
CNRX @CNRX --- --- 250
548 REVERSIBLE
COUNTER
CNTRX --- --- --- 247
549 TIMER RESET TRSET @TRSET --- --- 252
550 HUNDRED-MS TIMER TIMX --- --- --- 217
551 TEN-MS TIMER TIMHX --- --- --- 221
552 ONE-MS TIMER TMHHX --- --- --- 225
553 LONG TIMER TIMLX --- --- --- 237
554 MULTI-OUTPUT
TIMER
MTIMX --- --- --- 240
555 ACCUMULATIVE
TIMER
TTIMX --- --- --- 234
556 TENTH-MS TIMER TIMUX --- --- --- 228
557 HUNDREDTH-MS
TIMER
TMUHX --- --- --- 231
560 MOVE TO REGISTER MOVR @MOVR --- --- 304
561 MOVE TIMER/
COUNTER PV TO
REGISTER
MOVRW --- --- --- 304
562 DOUBLE DATA
EXCHANGE
XCGL @XCGL --- --- 298
565 BLOCK TRANSFER XFERC @XFERC --- --- 1118
566 SINGLE WORD DIS-
TRIBUTE
DISTC @DISTC --- --- 1120
567 DATA COLLECT COLLC @COLLC --- --- 1123
568 MOVE BIT MOVBC @MOVBC --- --- 1126
570 DOUBLE SHIFT LEFT ASLL @ASLL --- --- 315
571 DOUBLE SHIFT
RIGHT
ASRL @ASRL --- --- 317
572 DOUBLE ROTATE
LEFT
ROLL @ROLL --- --- 319
573 DOUBLE ROTATE
RIGHT
RORL @RORL --- --- 323
574 ROTATE LEFT
WITHOUT CARRY
RLNC @RLNC --- --- 321
575 ROTATE RIGHT
WITHOUT CARRY
RRNC @RRNC --- --- 325
576 DOUBLE ROTATE
LEFT WITHOUT
CARRY
RLNL @RLNL --- --- 321
577 DOUBLE ROTATE
RIGHT WITHOUT
CARRY
RRNL @RRNL --- --- 325
578 SHIFT N-BIT DATA
LEFT
NSFL @NSFL --- --- 329
579 SHIFT N-BIT DATA
RIGHT
NSFR @NSFR --- --- 329
580 SHIFT N-BITS LEFT NASL @NASL --- --- 332
581 SHIFT N-BITS RIGHT NASR @NASR --- --- 335
582 DOUBLE SHIFT
N-BITS LEFT
NSLL @NSLL --- --- 332
583 DOUBLE SHIFT
N-BITS RIGHT
NSRL @NSRL --- --- 335
590 INCREMENT BINARY ++ @++ --- --- 338
591 DOUBLE
INCREMENT BINARY
++L @++L --- --- 338
592 DECREMENT BINARY – – @– – --- --- 341
593 DOUBLE
DECREMENT BINARY
– –L @– –L --- --- 341
594 INCREMENT BCD ++B @++B --- --- 344
595 DOUBLE
INCREMENT BCD
++BL @++BL --- --- 344
Function code Instruction Mnemonic Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
