Omron CJ - INSTRUCTIONS - Page 1288

1250
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
N
O
MOVF MOVE FLOATING-
POINT (SINGLE)
469 @MOVF --- --- 514
MOVL DOUBLE MOVE 498 @MOVL --- --- 283
MOVR MOVE TO REGISTER 560 @MOVR --- --- 304
MOVRW MOVE TIMER/
COUNTER PV TO
REGISTER
561 --- --- --- 304
MSG DISPLAY MESSAGE 046 @MSG --- --- 1001
MSKR READ INTERRUPT
MASK
692 @MSKR --- --- 717
MSKS SET INTERRUPT
MASK
690 @MSKS --- --- 711
MTIM MULTI-OUTPUT
TIMER
543 --- --- --- 240
MTIMX MULTI-OUTPUT
TIMER
554 --- --- --- 240
MTR MATRIX INPUT 213 --- --- --- 818
MVN MOVE NOT 022 @MVN --- --- 286
MVNL DOUBLE MOVE NOT 499 @MVNL --- --- 286
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
NASL SHIFT N-BITS LEFT 580 @NASL --- --- 332
NASR SHIFT N-BITS RIGHT 581 @NASR --- --- 335
NCDMV PCU HIGH-SPEED
POSITIONING
218 @NCDMV --- --- 832
NCDTR PCU POSITIONING
TRIGGER
219 @NCDTR --- --- 836
NEG 2’S COMPLEMENT 160 @NEG --- --- 387
NEGL DOUBLE 2’S COM-
PLEMENT
161 @NEGL --- --- 387
NEXT FOR-NEXT LOOPS 513 --- --- --- 205
NOP NO OPERATION 000 --- --- --- 182
NOT NOT 520 --- --- --- 149
NSFL SHIFT N-BIT DATA
LEFT
578 @NSFL --- --- 329
NSFR SHIFT N-BIT DATA
RIGHT
579 @NSFR --- --- 329
NSLL DOUBLE SHIFT N-
BITS LEFT
582 @NSLL --- --- 332
NSRL DOUBLE SHIFT N-
BITS RIGHT
583 @NSRL --- --- 335
NUM4 ASCII TO FOUR-DIGIT
NUMBER
604 @NUM4 --- --- 435
NUM8 ASCII TO EIGHT-DIGIT
NUMBER
605 @NUM8 --- --- 435
NUM16 ASCII TO SIXTEEN-
DIGIT NUMBER
606 @NUM16 --- --- 435
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
OR OR --- @OR %OR !OR 144
OR < OR LESS THAN 310 --- --- --- 253
OR <$ OR STRING LESS
THAN
672 --- --- --- 1107
OR <> OR NOT EQUAL 305 --- --- --- 253
OR <>$ OR STRING NOT
EQUAL
671 --- --- --- 1107
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
