CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
U
W
X
TMUHX HUNDREDTH-MS
TIMER
557 --- --- --- 231
TOCV CONVERT ADDRESS
TO CV
285 @TOCV --- --- 1051
TPO TIME-PROPOR-
TIONAL OUTPUT
685 --- --- --- 665
TRSET TIMER RESET 549 @TRSET --- --- 252
TRSM TRACE MEMORY
SAMPLING
045 --- --- --- 1015
TSR READ SET TIMER 780 @TSR --- --- 1136
TSW SET STEP TIMER 781 @TSW --- --- 1136
TTIM ACCUMULATIVE
TIMER
087 --- --- --- 234
TTIMX ACCUMULATIVE
TIMER
555 --- --- --- 234
TWRIT WRITE TEXT FILE 704 @TWRIT --- --- 996
TXD TRANSMIT 236 @TXD --- --- 854
TXDU TRANSMIT VIA
SERIAL COMMUNICA-
TIONS UNIT
256 @TXDU --- --- 869
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
UP CONDITION ON 521 --- --- --- 150
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
WAIT NOT
(operand)
ONE CYCLE AND
WAIT NOT
805 --- --- --- 1069
WAIT (input
condition)
ONE CYCLE AND
WAIT
805 --- --- --- 1069
WAIT (operand) ONE CYCLE AND
WAIT
805 --- --- --- 1069
WDT EXTEND MAXIMUM
CYCLE TIME
094 @WDT --- --- 1042
WSFT WORD SHIFT 016 @WSFT --- --- 313
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
XCGL DOUBLE DATA
EXCHANGE
562 @XCGL --- --- 298
XCHG DATA EXCHANGE 073 @XCHG --- --- 298
XCHG$ EXCHANGE STRING 665 @XCHG$ --- --- 1101
XFER BLOCK TRANSFER 070 @XFER --- --- 294
XFERC BLOCK TRANSFER 565 @XFERC --- --- 1118
XFRB MULTIPLE BIT
TRANSFER
062 @XFRB --- --- 292
XNRL DOUBLE EXCLUSIVE
NOR
613 @XNRL --- --- 444
XNRW EXCLUSIVE NOR 037 @XNRW --- --- 444
XORL DOUBLE EXCLUSIVE
OR
612 @XORL --- --- 442
XORW EXCLUSIVE OR 036 @XORW --- --- 442
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
