CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
Appendix B Alphabetical List of Instructions by Mnemonic
App
Z
Symbols
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
ZCP AREA RANGE COM-
PAR E
088 --- --- --- 276
ZCPL DOUBLE AREA
RANGE COMPARE
116 --- --- --- 276
ZCPS SIGNED AREA
RANGE COMPARE
117 --- --- --- 280
ZCPSL DOUBLE SIGNED
AREA RANGE COM-
PAR E
118 --- --- --- 280
ZONE DEAD ZONE CON-
TROL
682 @ZONE --- --- 663
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
7SEG 7-SEGMENT DISPLAY
OUTPUT
214 --- --- --- 822
+ SIGNED BINARY ADD
WITHOUT CARRY
400 @+ --- --- 350
+$ CONCATENATE
STRING
656 @+$ --- --- 1086
++ INCREMENT BINARY 590 @++ --- --- 338
++B INCREMENT BCD 594 @++B --- --- 344
++BL DOUBLE INCRE-
MENT BCD
595 @++BL --- --- 344
++L DOUBLE INCRE-
MENT BINARY
591 @++L --- --- 338
+B BCD ADD WITHOUT
CARRY
404 @+B --- --- 354
+BC BCD ADD WITH
CARRY
406 @+BC --- --- 356
+BCL DOUBLE BCD ADD
WITH CARRY
407 @+BCL --- --- 356
+BL DOUBLE BCD ADD
WITHOUT CARRY
405 @+BL --- --- 354
+C SIGNED BINARY ADD
WITH CARRY
402 @+C --- --- 352
+CL DOUBLE SIGNED
BINARY ADD WITH
CARRY
403 @+CL --- --- 352
+D DOUBLE FLOATING-
POINT ADD
845 @+D --- --- 525
+F FLOATING-POINT
ADD
454 @+F --- --- 476
+L DOUBLE SIGNED
BINARY ADD WITH-
OUT CARRY
401 @+L --- --- 350
– SIGNED BINARY SUB-
TRACT WITHOUT
CARRY
410 @– --- --- 358
– – DECREMENT BINARY 592 @– – --- --- 341
– –B DECREMENT BCD 596 @– –B --- --- 347
– –BL DOUBLE DECRE-
MENT BCD
597 @– –BL --- --- 347
– –L DOUBLE DECRE-
MENT BINARY
593 @– –L --- --- 341
–B BCD SUBTRACT
WITHOUT CARRY
414 @–B --- --- 365
–BC BCD SUBTRACT
WITH CARRY
416 @–BC --- --- 368
–BCL DOUBLE BCD SUB-
TRACT WITH CARRY
417 @–BCL --- --- 368
