z Differences between Interlocks and Jumps
The following table shows the differences between interlocks (created with IL(002)/ILC(003),
MILH(517)/MILC(519), or MILR(518)/MILC(519)) and jumps created with JMP(004)/JME(005).
Item
Treatment in IL(002)/ILC(003),
MILH(517)/MILC(519), or
MILR(518)/MILC(519))
Treatment in
JMP(004)/JME(005)
Instruction execution Except OUT, OUT NOT, OUTB(534), and
timer instructions, all instructions are not
executed.
No instructions are executed.
Output status in instructions Except for outputs in OUT, OUT NOT,
OUTB(534), and timer instructions, all out-
puts retain their previous status.
All outputs retain their previous status.
Bits in OUT, OUT NOT,
OUTB(534)
OFF All outputs retain their previous status.
Status of timer instructions
(except (TTIM(087),
TTIMX(555), MTIM(543), and
MTIMX(554))
Reset Operating timers (TIM, TIMX(550),
TIMH(015), TIMHX(551), TMHH(540),
TMHHX(552), TIMU(541), TIMUX(556),
TMUH(544), TMUHX(557) only) continue
timing because the PVs are updated even
when the timer instruction is not being exe-
cuted.
