3. Instructions
416
CS/CJ/NSJ Series Instructions Reference Manual (W474)
z Operand Specifications
BINS
BISL
Flags
Area
Word addresses
Indirect DM/EM
addresses
Con-
stants
Registers Flags
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
TK CF
C
OK OK OK OK OK OK OK OK OK OK
OK
OK --- OK --- --- --- ---S
---
D
Area
Word addresses
Indirect DM/EM
addresses
Con-
stants
Registers Flags
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
TK CF
C
OK OK OK OK OK OK OK OK OK OK
OK OK
--- OK --- --- --- ---S
--- ---
D
Name Label Operation
Error Flag ER • ON if C is not within the specified range of 0000 to 0003.
• ON if C=0002 and the leftmost digit of S/S+1 is A to E.
• ON if C=0003 and the leftmost digit of S/S+1 is B to E.
• ON if the content of S/S+1 and S is not BCD.
• OFF in all other cases.
Equal Flag = • ON if D/D+1 contains 0000 0000 after execution.
• OFF in all other cases.
Negative Flag N • ON if bit 15 of D/D+1 is ON after execution.
• OFF in all other cases.
