3. Instructions
926
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Note 1 The following two methods can be used to send data to the host computer through a serial port with the host link
while initiating communications from the PLC.
1) Set the destination unit address (bits 00 to 07 of C+2) to the unit address of the CPU Unit or Serial Communica-
tions Unit/Board and set the serial port number (bits 08 to 11 of C+1) to 1 for port 1 or 2 for port 2.
2) Set the destination unit address directly into bits 00 to 07 of C+2. In this case, set the serial port number in bits 08
to 11 of C+1 to 0 for direct specification.
• Serial Communication Unit ports
• Serial Communication Board ports
• CPU Unit ports
2 When specifying the serial port without a routing table for the serial gateway function (conversion to host link FINS),
set the serial port's unit address in the destination network address byte.
3 Set the destination network address to 00 to transmit within the local network. When two or more CPU Bus Units are
mounted, the network address will be the unit number of the Unit with the lowest unit number.
4 For a broadcast transmission, set #FF hex.
To send within the same node, set #00 hex.
Unit address
(C+2, bits 00 to 07)
Unit
Serial port number
(C+1, bits 08 to 11)
Serial port
00 hex CPU Unit 1 hex Built-in RS-232C port
2 hex Peripheral port
10 hex + unit number Serial Communications Unit (CPU Bus Unit) 1 hex Port 1
2 hex Port 2
E1 hex Serial Communications Board (Inner Board)
(CS Series only)
1 hex Port 1
2 hex Port 2
Port Port’s unit address Example: Unit number = 1
Port 1 80 hex + 4 × unit number 80 + 4 × 1 = 84 hex (132 decimal)
Port 2 81 hex + 4 × unit number 81 + 4 × 1 = 85 hex (133 decimal)
Port Port’s unit address
Port 1 E4 hex (228 decimal)
Port 2 E5 hex (229 decimal)
Port Port’s unit address
Peripheral FD hex (253 decimal)
RS-232C FC hex (252 decimal)
C+3
Resend times
#0 to F (0 to 15)
#0: Fixed
8
111215
0347
Logical port number
#0 to 7 (#F: automatic allocation)
Response needed / not needed (See note 5.)
#0: Response needed
#9: Response not needed
C+4
0
15
Response monitor time
&1 to 65535 (#0001 to FFFF hex)
0.1 to 6553.5 sec
#0000:2s (default value)
