Omron CJ2M-CPU Series User Manual

6 Interrupts
6-16
CJ2M CPU Unit Pulse I/O Module User’s Manual
Ladder Program Example
Cyclic Task
Interrupt Task 142
Interrupt input 2
Interrupt input 2
Specifies executing
interrupt when input
turns ON.
Unmasks the
interrupt input.
The MSKS instruction is used
to specify an interrupt when the
input turns ON and then it is
used to unmask the interrupt
input.
Reset input
P_First_Cycle
2961.00
2961.01
2961.02
2961.03
2961.04
2960.04
OK output
NG output 2
NG output 3
NG output 4
NG output 1
Sensor input 1
Sensor input 1
Sensor input 2
Sensor input 2
Sensor input 3
Sensor input 3
OK output
NG output 2
NG output 3
NG output 4
2960.00
2960.00
2960.01
2960.03
2960.01 2960.03
2961.00
2961.02
2961.03
2961.04
2961.01
2960.00
2960.01
2960.03
Sensor input 1
Sensor input 2
Sensor input 3
NG output 1
!
!
!

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
