Text String Processing Instructions Section 3-31
S3: Beginning Position (0000 to 0FFF hex or &0 to &4095)
Note (1) The data from S1 to S1 + the maximum 2,047 words, from S2 to S2 + the
maximum 2,047 words, and from D to D + the maximum 2,047 words
must be in the same area.
(2) The data from S2 to S2 + the maximum 2,047 words and from D to D +
the maximum 2,047 words cannot overlap. The data from S1 to S1 + the
maximum 2,047 words and from D to D + the maximum 2,047 words can
overlap. The data from S1 to S1 + the maximum 2,047 words and from
S2 to S2 + the maximum 2,047 words can also overlap.
Operand Specifications
15 0
D
to
Text string data: 4,095 characters max. + NUL
D + maximum 2,047 words
Area S1 S2 S3 D
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A447
A448 to A959
A448 to
A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants --- #0000 to
#0FFF
(binary) or
&0 to &4095
---
Data Registers --- DR0 to DR15 ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
