Timer and Counter Instructions Section 3-5
Basic Timer
Specifications
The following table shows the basic specifications of the timers.
Note (1) TIM PVs are refreshed at execution for all times and also every 100 ms
for T0000 to T0015.
(2) TIMH(015)/TIMHX(551) PVs are refreshed at execution for all times and
also every 10 ms for T0000 to T0015.
Timer Operation The following table shows the effects of operating and programming condi-
tions on the operation of the timers.
Item TIM/TIMX(550) TIMH(015)/
TIMHX(551)
TMHH(540)/
TMHHX(552)
TTIM(087)/
TTIMX(555)
TIML(542)/
TIMLX(553)
MTIM(543)/
MTIMX(554)
Timing
method
Decrementing Decrementing Decrementing Incrementing Decrementing Incrementing
Timing units 0.1 s 0.01 s 0.001 s 0.1 s 0.1 s 0.1 s
Max. SV TIM: 999.9 s
TIMX: 6,553.5
s
TIMH: 99.99 s
TIMHX:
655.35 s
TMHH: 9.999 s
TMHHX:
65.535 s
TTIM: 999.9 s
TTIMX:
6,553.5 s
TIML: 115 days
TIMLX:
49,710 days
MTIM: 999.9 s
MTIMX:
6,553.5 s
Outputs/
instruction
11111 8
Timer num-
bers
Used Used Used Used Not used Not used
Comp. flag
refreshing
At execution At execution By interrupt
every 1 ms
At execution At execution At execution
Timer PV
refreshing
See note 1. See note 2. Every 1 ms At execution At execution At execution
Value
after
reset
Comp.
flags
OFF OFF OFF OFF OFF OFF
PVs SV SV SV 0 SV 0
Item TIM/
TIMX(550)
TIMH(015)/
TIMHX(551)
TMHH(540)/
TMHHX(552)
TTIM(087)/
TTIMX(555)
TIML(542)/
TIMLX(553)
MTIM(543)/
MTIMX(554)
Operating mode change PV = 0
Completion Flag = OFF
--- ---
Power interrupt/reset PV = 0
Completion Flag = OFF
--- ---
Execution of CNR(545)/
CNRX(547)
Binary: PV = FFFF, Completion Flag = OFF
BCD: PV = FFFF or 9999, Completion Flag = OFF
Not applicable Not applicable
Operation in jumped pro-
gram section
(JMP(004)-JME(005))
Operating timers continue timing. Timer status is maintained.
Operation in interlocked
program section
(IL(002)-ILC(003))
PV = SV
Completion Flag = OFF
Timer status
maintained.
PV = SV
Comp. flag =
OFF
Timer status
maintained.
Forced
set
Comp. flags ON --- ---
PVs Set to 0. --- ---
Forced
reset
Comp. flags OFF --- ---
PVs Reset to SV. Set to 0. --- ---
