Sequence Output Instructions Section 3-3
3-3-5 SET and RESET: SET and RSET
Purpose SET turns the operand bit ON when the execution condition is ON.
RSET turns the operand bit OFF when the execution condition is ON.
Ladder Symbols
Variations
Applicable Program Areas
Operand Specifications
SET
B
RSET
B
B: Bit
B: Bit
Variations Executed Each Cycle for ON Condition SET
Executed Once for Upward Differentiation @SET
Executed Once for Downward Differentiation %SET
Immediate Refreshing Specification !SET
Combined
variations
Executed Once and Bit Refreshed
Immediately for Upward Differentiation
!@SET
Executed Once and Bit Refreshed
Immediately for Downward Differentiation
!%SET
Variations Executed Each Cycle for ON Condition RSET
Executed Once for Upward Differentiation @RSET
Executed Once for Downward Differentiation %RSET
Immediate Refreshing Specification !RSET
Combined
Variations
Immediate Refreshing Once for Upward
Differentiation
!@RSET
Immediate Refreshing Once for Downward
Differentiation
!%RSET
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area B
CIO Area CIO 0.00 to CIO 6143.15
Work Area W0.00 to W511.15
Holding Bit Area H0.00 to H511.15
Auxiliary Bit Area A448.00 to A959.15
Timer Area ---
Counter Area ---
DM Area ---
Indirect DM addresses
in binary
---
Indirect DM addresses
in BCD
---
Constants ---
Data Registers ---
