Sequence Input Instructions Section 3-2
The AND LOAD instruction can be used repeatedly. In programming method
(2) above, however, the number of AND LOAD instructions becomes one less
than the number of LOAD and LOAD NOT instructions before that.
In method (2), make sure that the total number of LOAD and LOAD NOT
instructions before AND LOAD is not more than eight. To use nine or more,
program using method (1). If there are nine or more with method (2), then a
program error will occur during the program check by the CX-Programmer.
Coding
Second LD: Used for first bit of next block connected in series to previous
block.
3-2-8 OR LOAD: OR LD
Purpose Takes a logical OR between logic blocks.
Ladder Symbol
Variations
Applicable Program Areas
AND LD ---
AND LD ---
.
.
.
.
OUT 100.00
Address Instruction Operand
000000 LD 0.00
000001 OR 0.01
000002 LD 0.02
000003 OR NOT 0.03
000004 AND LD ---
000005 OUT 100.00
Instruction Operand
Logic block
Logic block
Variations Creates ON Each Cycle AND Result is ON OR LD
Immediate Refreshing Specification Not supported.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
