Network Instructions Section 3-24
3-24-8 EXPLICIT SET ATTRIBUTE: ESATR(722)
Purpose Sends an information write command in an explicit message (Set Attribute
Single, ServiceCode: 10 hex).
This instruction can be used in the CP1H CPU Units only. It cannot be used in
the CP1L CPU Units. If ESATR(722) is used in a CP1L CPU Unit, Error Flag
(ER) will be turned ON.
Ladder Symbol
Variations
Applicable Program Areas
ESATR(722)
S
C
S: First word of send message
C: First control word
Variations Executed Each Cycle for ON Condition ESATR(722)
Executed Once for Upward Differentiation @ESATR(722)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
