Model Conversion Instructions Section 3-33
3-33-1 BLOCK TRANSFER: XFERC(565)
Purpose Transfers the specified number of consecutive words.
Ladder Symbol
Variations
Applicable Program Areas
Operands N: Number of Words
Specifies the number of words to be transferred. The possible range for N is
0000 to 9999 BCD.
S: First Source Word
Specifies the first source word.
D: First Destination Word
Specifies the first destination word.
Operand Specifications
XFERC(565)
N
S
D
N: Number of words
S: First source word
D: First destination word
Variations Executed Each Cycle for ON Condition XFERC(565)
Executed Once for Upward Differentiation @XFERC(565)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
15 0
S
S+(N−1)
to to
15 0
D
D+(N−1)
to to
Area N S D
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
