Model Conversion Instructions Section 3-33
Applicable Program Areas
Operands Bs: Source Base Address
Specifies the source base address. The offset is added to this address to cal-
culate the source word.
Of: Offset
The value of Of determines the operation of COLLC(567).
• Data Collect Operation (Of = 0000 to 7999 BCD)
The Of value is added to the base address to calculate the source word.
The offset can be any value from 0000 to 7999 BCD, but Bs and Bs+Of
must be in the same data area.
• LIFO Stack Read Operation (Of = 8000 to 8999 BCD)
If the leftmost digit of Of is 8, COLLC(567) will operate as a LIFO stack
instruction. The stack begins at Bs with a length specified in the rightmost
3 digits of Of.
• FIFO Stack Read Operation (Of = 9000 to 9999 BCD)
If the leftmost digit of Of is 9, COLLC(567) will operate as a FIFO stack
instruction. The stack begins at Bs with a length specified in the rightmost
3 digits of Of.
Operand Specifications
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
15 0
to
to
Bs
Bs+Of
Area Bs Of D
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants --- #0000 to #7999 for
Data Collection
#8000 to #8999 for
LIFO Stack Read
#9000 to #9999 for
FIFO Stack Read
---
Data Registers --- DR0 to DR15
