Model Conversion Instructions Section 3-33
3-33-4 MOVE BIT: MOVBC(568)
Purpose Transfers the specified bit.
Ladder Symbol
Variations
Applicable Program Areas
Operands C: Control Word
The rightmost two digits of C indicate which bit of S is the source bit and the
leftmost two digits of C indicate which bit of D is the destination bit.
Operand Specifications
S
C
D
MOVBC(568)
S: Source word or data
C: Control word
D: Destination word
Variations Executed Each Cycle for ON Condition MOVBC(568)
Executed Once for Upward Differentiation @MOVBC(568)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
15 8 07
C
Source bit: 00 to 15
(Two-digit BCD)
Destination bit: 00 to 15
(Two-digit BCD)
mn
Area S C D
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants #0000 to #FFFF
(binary)
Specified values
only
---
Data Registers DR0 to DR15
