Model Conversion Instructions Section 3-33
Applicable Program Areas
Operands S: Source data
Specifies the variable or address for which the variable type and word address
will be retrieved.
D1: Variable code
Contains the FINS variable type code (data area code) of the source data.
D2: Word address
Contains the word address of the source data in 4-digit hexadecimal.
Operand Specifications
Description GETID(286) retrieves the data area address of the specified source variable
or address, outputs the data area code to D1 in 4-digit hexadecimal, and out-
puts the word address number to D2 in 4-digit hexadecimal.
The following table shows the variable type (data area) codes and corre-
sponding address ranges for the PLC’s data areas.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area S D1 D2
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants ---
Data Registers DR0 to DR15
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Data area Data
size
Data area code
(Output to D1.)
Address
(Output to D2.)
CIO Area CIO Word 00B0 hex 0000 to 17FF hex
(0000 to 6143)
Work Area W 00B1 hex 0000 to 01FF hex
(000 to 511)
Holding Bit Area H 00B2 hex 0000 to 01FF hex
(000 to 511)
Auxiliary Bit Area 00B3 hex 0000 to 03BF hex
(000 to 959)
DM Area 0082 hex 0000 to 7FFF hex
(00000 to 32767)
