1087
Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Task Control Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Model Conversion Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Special Function Block Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
String Comparison
Instructions
LD, AND, OR +=$ 670 4 64.47 63.6 Comparing 1 character with 1
character
LD, AND, OR +<>$ 671
LD, AND, OR +<$ 672
LD, AND, OR +<=$ 673
LD, AND, OR +>$ 674
LD, AND, OR +>=$ 675
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
TASK ON TKON 820 2 30.65 23.2 ---
TASK OFF TKOF 821 2 18.30 23.4 ---
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
BLOCK TRANSFER XFERC 565 4 37.04 24.5 Transferring 1 word
2.922
ms
4.65
ms
Transferring 1,000 words
SINGLE WORD
DISTRIBUTE
DISTC 566 4 24.80 34.9 Data distribute
35.57 45.0 Stack operation
DATA COLLECT COLLC 567 4 29.83 36.6 Data distribute
30.13 39.2 Stack operation
31.10 39.2 Stack operation
1 word FIFO Read
8.100
ms
14.7
ms
Stack operation
1,000 word FIFO Read
MOVE BIT MOVBC 568 4 28.03 34.9 ---
BIT COUNTER BCNTC 621 4 32.97 41.5 Counting 1 word
5.703
ms
6.09
ms
Counting 1,000 words
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
GET VARIABLE ID GETID 286 4 26.5 32.8 ---
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
