153
Sequence Control Instructions Section 3-4
Examples When W0.00 and W0.01 are both ON, the instructions between MILH(517)
with interlock number 0 and MILC(519) with interlock number 0 are executed
normally.
When W0.00 is OFF, the instructions between MILH(517) with interlock num-
ber 0 and MILC(519) with interlock number 0 are interlocked.
When W0.00 is ON and W0.01 are OFF, the instructions between MILH(517)
with interlock number 1 and MILC(519) with interlock number 1 are inter-
locked. The other instructions are executed normally.
a
IL
ILC
A1
MILC
0
A2
The MILC(519) instruction is ignored.
When input condition "a" is OFF, program
sections A1 and A2 are both interlocked.
W0.00
0.01
0.02
200.00
H0.00
OFF
OFF
W0.00 OFF
MILH
0
100.00
W0.01
MILH
1
100.01
CNT
1
#10
SET
110.03
MILC
1
MILC
0
W0.00 and W0.01
both ON
W0.00 ON and W0.01
OFF
Executed
normally.
Executed
normally.
Outputs
interlocked.
Outputs
interlocked.
Held
Held
Executed
normally.
To Next Page
