Sequence Control Instructions Section 3-4
Ladder Symbols
Variations
Applicable Program Areas
Operands N: Jump Number
The jump number must be 0000 to 00FF (0 to 255 decimal).
Operand Specifications
Description The operation of CJP(510) and CJPN(511) differs only in the execution condi-
tion. CJP(510) jumps to the first JME(005) when the execution condition is ON
and CJPN(511) jumps to the first JME(005) when the execution condition is
OFF.
CJP(510)
N
CJPN(511)
N
N: Jump number
N: Jump number
Variations Jumps when ON/Does Not Jump when OFF CJP(510)
Immediate Refreshing Specification Not supported
Variations Jumps when OFF/Does Not Jump when ON CJPN(511)
Immediate Refreshing Specification Not supported
Variations Executed Each Cycle for ON Condition JME(005)
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK Not allowed OK OK
Area N
CJP(510) CJPN(511) JME(005)
CIO Area CIO 0 to CIO 6143 ---
Work Area W0 to W511 ---
Holding Bit Area H0 to H511 ---
Auxiliary Bit Area A0 to A959 ---
Timer Area T0000 to T4095 ---
Counter Area C0000 to C4095 ---
DM Area D0 to D32767 ---
Indirect DM
addresses in binary
@ D0 to @ D32767 ---
Indirect DM
addresses in BCD
*D0 to *D32767 ---
Constants #0000 to #00FF (binary) or &0 to &255 #0000 to #00FF
(binary) or &0 to
&255
Data Registers DR0 to DR15 ---
Index Registers --- ---
Indirect addressing
using Index Regis-
ters
,IR0 to ,IR15
ā2048 to +2047, IR0 to ā2048 to +2047,
IR15
DR0 to DR15, IR0 to IR15
---
