Timer and Counter Instructions Section 3-5
Applicable Program Areas
Operands D1: Completion Flag
Bit 0 of D1 acts as the Completion Flag for TIML(542)/TIMLX(553).
D2: PV Word
D2+1 and D2 contain the 8-digit binary or BCD PV. (D2 and D2+1 must be in
the same data area.) The PV can range from #00000000 to #99999999 for
TIML(542) and &00000000 to &4294967295 (decimal) or #00000000 to
#FFFFFFFF (hexadecimal) for TIMLX(553).
S: SV Word
S+1 and S contain the 8-digit binary or BCD SV. (S and S+1 must be in the
same data area.) The SV must be between #00000000 to #99999999 for
TIML(542) and &00000000 to &4294967294 (decimal) or #00000000 to
#FFFFFFFF (hexadecimal) for TIMLX(553).
Operand Specifications
Block program areas Step program areas Subroutines Interrupt tasks
Not allowed OK OK Not allowed
15
D1
0
Completion Flag
Do not use.
D2D2+1
D2
SS+1
S
Area D1 D2 S
CIO Area CIO 0 to
CIO 6143
CIO 0 to CIO 6142
Work Area W0 to W511 W0 to W510
Holding Bit Area H0 to H511 H0 to H510
Auxiliary Bit Area A448 to A959 A448 to A958 A0 to A958
Timer Area --- --- T0000 to T4094
Counter Area --- --- C0000 to C4094
DM Area D0 to D32767 D0 to D32766
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants --- BCD:
#00000000 to
99999999 (BCD)
ā&ā cannot be
used.
Binary:
&00000000 to
&4294967295
(decimal) or
#00000000 to
#FFFFFFFF (hex)
Data Registers ---
