Omron CP - PROGRAMMING MANUAL 05-2007 - Page 225

192
Timer and Counter Instructions Section 3-5
D1: 200
D2: D100
S: D200
S+1: D201
S+2: D202
S+3: D203
S+4: D204
S+5: D205
S+6: D206
S+7: D207
0.00
200
D100
D200
Reset bit
Completion Flags
Timer PV
Timer SVs
(Incrementing)
Pause bit
Corresponding completion
flag ON when SV ≤ PV.
CIO 0.00
CIO 200.08
CIO 200.09
SV 7
SV 1
SV 0
200.00
200.01
200.07
Timer input
Timer SVs
Reset bit
PV maintained.
Timing resumes.
Completion Flags
Pause bit
Max. PV = 9999
Timer input must remain ON
while the timer is timing.
