Omron CP - PROGRAMMING MANUAL 05-2007 - Page 272

239
Comparison Instructions Section 3-6
R: First result word
Each bit of each R word contains the result of a comparison between S and
one of the ranges defined the comparison block. The maximum number of
result words is 16, i.e., m equals 0 to 15.
Operand Specifications
15 014
Comparison result for
S and range 16m + 14
Comparison result for
S and range 16m + n
Comparison result for
S and range 16m
Comparison result for
S and ran
g
e 16m + 15
R+m
n
Area S B R
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants #0000 to #FFFF
(binary)
&0 to &65535
(unsigned deci-
mal)
−32768 to 0
32767 (signed
decimal)
---
Data Registers DR0 to DR15 ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
