Data Movement Instructions Section 3-7
3-7-12 SINGLE WORD DISTRIBUTE: DIST(080)
Purpose Transfers the source word to a destination word calculated by adding an offset
value to the base address.
Ladder Symbol
Variations
Applicable Program Areas
Operands Bs: Destination Base Address
Specifies the destination base address. The offset is added to this address to
calculate the destination word.
Of: Offset
This value is added to the base address to calculate the destination word. The
offset can be any value from 0000 to FFFF (0 to 65,535 decimal), but Bs and
Bs+Of must be in the same data area.
Operand Specifications
DIST(080)
S
S: Source word
Bs: Destination base address
Of: Offset
Bs
Of
Variations Executed Each Cycle for ON Condition DIST(080)
Executed Once for Upward Differentiation @DIST(080)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
15 0
to
to
Bs
Bs+Of
Area S Bs Of
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959 A448 to A959 A0 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants #0000 to #FFFF
(binary)
--- #0000 to #FFFF
(binary) or &0 to
&65535
Data Registers DR0 to DR15 --- DR0 to DR15
