337
Symbol Math Instructions Section 3-10
3-10-1 SIGNED BINARY ADD WITHOUT CARRY: +(400)
Purpose Adds 4-digit (single-word) hexadecimal data and/or constants.
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
DOUBLE SIGNED BINARY
MULTIPLY
*L 421 371
UNSIGNED BINARY MULTI-
PLY
*U 422 372
DOUBLE UNSIGNED BINARY
MULTIPLY
*UL 423 374
BCD MULTIPLY *B 424 375
DOUBLE BCD MULTIPLY *BL 425 377
SIGNED BINARY DIVIDE / 430 378
DOUBLE SIGNED BINARY
DIVIDE
/L 431 380
UNSIGNED BINARY DIVIDE /U 432 382
DOUBLE UNSIGNED BINARY
DIVIDE
/UL 433 384
BCD DIVIDE /B 434 385
DOUBLE BCD DIVIDE /BL 435 387
Instruction Mnemonic Function code Page
+(400)
R
Au
Ad
Au: Augend word
Ad: Addend word
R: Result word
Variations Executed Each Cycle for ON Condition +(400)
Executed Once for Upward Differentiation @+(400)
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area Au Ad R
CIO Area CIO 0 to CIO 6143
Work Area W0 to W511
Holding Bit Area H0 to H511
Auxiliary Bit Area A0 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
To Next Page
