Symbol Math Instructions Section 3-10
3-10-4 DOUBLE SIGNED BINARY ADD WITH CARRY: +CL(403)
Purpose Adds 8-digit (double-word) hexadecimal data and/or constants with the Carry
Flag (CY).
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
+CL(403)
Au
Ad
R
Au: 1st augend word
Ad: 1st addend word
R: 1st result word
Variations Executed Each Cycle for ON Condition +CL(403)
Executed Once for Upward Differentiation @+CL(403)
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area Au Ad R
CIO Area CIO 0 to CIO 6142
Work Area W0 to W510
Holding Bit Area H0 to H510
Auxiliary Bit Area A0 to A958 A448 to A958
Timer Area T0000 to T4094
Counter Area C0000 to C4094
DM Area D0 to D32766
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants #00000000 to #FFFFFFFF (binary)
&0 to &4294967295 (unsigned deci-
mal)
−2147483648 to 2147483647 (signed
decimal)
---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
