380
Symbol Math Instructions Section 3-10
Flags
Precautions When the content of Dr is 0, an error will be generated and the Error Flag will
turn ON.
If as a result of the division, the content of R is 0000 hex, the Equals Flag will
turn ON.
If as a result of the division, the content of the leftmost bit of R is 1, the Nega-
tive Flag will turn ON.
Examples When CIO 0.00 is ON in the following example, D100 will be divided by D110
as 4-digit signed binary values, the quotient will be output to D120, and the
remainder to D121.
3-10-24 DOUBLE SIGNED BINARY DIVIDE: /L(431)
Purpose Divides 8-digit (double-word) signed hexadecimal data and/or constants.
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
Name Label Operation
Error Flag ER ON when the result is 0.
OFF in all other cases.
Equals Flag = ON when as a result of the division, R is 0.
OFF in all other cases.
Negative Flag N ON when the leftmost bit of the R is 1.
OFF in all other cases.
0.00
D100
D110
D120
/L(431)
R
Dd
Dr
Dd: 1st dividend word
Dr: 1st divisor word
R: 1st result word
Variations Executed Each Cycle for ON Condition /L(431)
Executed Once for Upward Differentiation @/L(431)
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area Dd Dr R
CIO Area CIO 0 to CIO 6142 CIO 0 to
CIO 6140
Work Area W0 to W510 W0 to W508
Holding Bit Area H0 to H510 H0 to H508
