390
Conversion Instructions Section 3-11
Description BIN(023) converts the BCD data in S to binary data and writes the result to R.
Flags
Example The following diagram shows an example BCD-to-binary conversion.
3-11-2 DOUBLE BCD-TO-DOUBLE BINARY: BINL(058)
Purpose Converts 8-digit BCD data to 8-digit hexadecimal (32-bit binary) data.
Ladder Symbol
Variations
Auxiliary Bit Area A0 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants ---
Data Registers DR0 to DR15
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Area S R
(BCD) (BIN)
R
Name Label Operation
Error Flag ER ON if the content of S is not BCD.
OFF in all other cases.
Equals Flag = ON if the result is 0000.
OFF in all other cases.
Negative Flag N OFF
×10
3
×10
2
×10
1
×10
0
×16
3
×16
2
×16
1
×16
0
R
BINL(058)
S
R
S: First source word
R: First result word
Variations Executed Each Cycle for ON Condition BINL(058)
Executed Once for Upward Differentiation @BINL(058)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
