Conversion Instructions Section 3-11
Applicable Program Areas
Operands S: First Source Word
The content of S+1 and S must be between 0000 0000 and 05F5 E0FF hexa-
decimal (0000 0000 and 9999 9999 decimal).
Operand Specifications
Description BCDL(059) converts the 8-digit hexadecimal (32-bit binary) data in S and S+1
to 8-digit BCD data and writes the result to R and R+1.
Flags
Precautions The content of S+1 and S must not exceed 05F5 E0FF (9999 9999 decimal).
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area S R
CIO Area CIO 0 to CIO 6142
Work Area W0 to W510
Holding Bit Area H0 to H510
Auxiliary Bit Area A0 to A958 A448 to A958
Timer Area T0000 to T4094
Counter Area C0000 to C4094
DM Area D0 to D32766
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants ---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
RR+1
(BCD)
(BCD)
S+1
S
(BIN) (BIN)
Name Label Operation
Error Flag ER ON if the contents of S and S+1 exceed 05F5 E0FF
(9999 9999 decimal).
OFF in all other cases.
Equals Flag = ON if the result is 0.
OFF in all other cases.
