Special Math Instructions Section 3-13
Setting the Data Format in Control Word C
• 16-bit Unsigned BCD Data
The input data and/or the output data can be 16-bit unsigned BCD data.
Also, the linear extrapolation function can be set to operate on the value
specified in S directly or on X
m
–S. (X
m
is the maximum value of X in the
line-segment data.)
• 16-bit Unsigned Binary Data
The input data and/or the output data can be 16-bit unsigned binary data.
Also, the linear extrapolation function can be set to operate on the value
specified in S directly or on X
m
–S. (X
m
is the maximum value of X in the
line-segment data.)
• 16-bit Signed Binary Data
• 32-bit Signed Binary Data
Setting name Bit in C Setting
Input data (S) format 15 0: Binary
1: BCD
Output data (D) format 14 0: Binary
1: BCD
Source data form 13 0: Operate on S
1: Operate on X
m
–S
Signed data specification for S and D 11 0: Unsigned data
Data length specification for S and D 10 Invalid (fixed at 16 bits)
Floating-point specification 09 0: Integer data
Setting name Bit in C Setting
Input data (S) format 15 0: Binary
1: BCD
Output data (D) format 14 0: Binary
1: BCD
Source data form 13 0: Operate on S
1: Operate on X
m
–S
Signed data specification for S and D 11 0: Unsigned data
Data length specification for S and D 10 Invalid (fixed at 16 bits)
Floating-point specification 09 0: Integer data
Setting name Bit in C Setting
Input data (S) format 15 0: Binary
Output data (D) format 14 0: Binary
Source data form 13 0
Signed data specification for S and D 11 1: Signed data
Data length specification for S and D 10 0: 16-bit signed binary data
Floating-point specification 09 0: Integer data
Setting name Bit in C Setting
Input data (S) format 15 0: Binary
Output data (D) format 14 0: Binary
Source data form 13 0
Signed data specification for S and D 11 1: Signed data
Data length specification for S and D 10 1: 32-bit signed binary data
Floating-point specification 09 0: Integer data
