Table Data Processing Instructions Section 3-16
Applicable Program Areas
Operands C and C+1: Control words
C specifies the number of units (bytes or words) to be summed. (Bit 13 of C+1
determines whether bytes or words are being summed.)
Bits 12 to 15 of C+1 indicate what type of data is being summed, as shown in
the following diagram.
R1: First word in range
R1 specifies the first word in the range. The length of the range depends on
the number of units as well as the starting byte, if bytes are being added.
D: First destination word
The result of the calculation is output to D+1 and D. The leftmost four digits
are stored in D+1 and the rightmost four digits are stored in D.
Operand Specifications
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
15 0
C
15 014
0
C+1
13 12 11
0000 0000 0000
Data type (Effective if bit 14 is 0.)
Data type
Units
Starting byte (Effective if bit 13 is 1.)
0: Unsigned binary data
1: Signed binary data
0: Binary
1: BCD
0: Words
1: Bytes
0: Leftmost byte
1: Rightmost byte
Number of words/bytes in range
R1
15 0
---
R1+(C units–1)
to
Calculation range
Area C R1 D
CIO Area CIO 0 to
CIO 6142
CIO 0 to
CIO 6143
CIO 0 to
CIO 6142
Work Area W0 to W510 W0 to W511 W0 to W510
Holding Bit Area H0 to H510 H0 to H511 H0 to H510
Auxiliary Bit Area A0 to A958 A0 to A959 A448 to A958
Timer Area T0000 to T4094 T0000 to T4095 T0000 to T4094
Counter Area C0000 to C4094 C0000 to C4095 C0000 to C4094
