Data Control Instructions Section 3-17
Operands The contents of the five words starting with the first parameter word (P1) are
shown in the following diagram.
Operand Specifications
∆Y
∆X
P1
P1+1
P1+2
P1+3
P1+4
15 0
15
0
15 0
15
0
15
0
Offset of linear function
8000 to 7FFF (signed binary)
0001 to 9999 (BCD)
8000 to 7FFF (signed binary)
Maximum conversion
8000 to 7FFF (signed binary)
Minimum conversion
8000 to 7FFF (signed binary)
Area S P1 R
CIO Area CIO 0 to
CIO 6143
CIO 0 to
CIO 6139
CIO 0 to
CIO 6143
Work Area W0 to W511 W0 to W507 W0 to W511
Holding Bit Area H0 to H511 H0 to H507 H0 to H511
Auxiliary Bit Area A0 to A447
A448 to A959
A0 to A443
A448 to A955
A448 to A959
Timer Area T0000 to T4095 T0000 to T4091 T0000 to T4095
Counter Area C0000 to C4095 C0000 to C4091 C0000 to C4095
DM Area D0 to D32767 D0 to D32763 D0 to D32767
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants ---
Data Registers DR0 to DR15 --- DR0 to DR15
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
