Interrupt Control Instructions Section 3-19
Starting Scheduled Interrupts while Resetting the Scheduled Interrupt
Timer
When W0.01 turns ON in the following example, MSKS(690) sets the sched-
ule interrupt interval for schedule interrupt 0 to 10.5 ms (assuming the unit is
set to 0.1 ms in the PLC Setup), resets the internal timer, and starts the inter-
nal timer.
3-19-2 READ INTERRUPT MASK: MSKR(692)
Purpose Reads the current interrupt processing settings that were set with
MSKS(690).
Ladder Symbol
Variations
Applicable Program Areas
MSKS
14
&105
W0.01
N
S
MSKR(692)
N
D
N: Interrupt identifie
D: Destination word
Variations Executed Each Cycle for ON Condition MSKR(692)
Executed Once for Upward Differentiation @MSKR(692)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
