Network Instructions Section 3-24
Operand Specifications
Description Sends the explicit message command (stored in the range of words beginning
at S+2) to the node address specified in S+1, via the Communications Unit
with the FINS unit address specified in bits 00 to 07 of C+1. When the
response to the explicit message is received, it is stored in the range of words
beginning at D+2.
Number of Bytes Settings
The number of bytes of send data in S includes the 10 bytes in S+1 to S+5 as
well as the number of bytes of service data beginning at S+6. (For example, if
there is 1 byte of service data, there are 11 bytes of data all together, so S
must be set to 000B hex.)
The number of bytes of received data in D includes the 4 bytes in D+1 and
D+2 as well as the number of bytes of service data beginning at D+3. (For
example, if there is 1 byte of service data, there are 5 bytes of data all
together and D contains 0005 hex.)
The setting in bits 12 to 15 of C+1 (0 or 8 hex) determines the byte-order of
the service data stored at S+6 and D+3.
• Storing Data from the Leftmost Byte
Set bits 12 to 15 of C+1 to 0 hex.
Area S D C
CIO Area CIO 0 to CIO 6143 CIO 0 to CIO 6140
Work Area W0 to W511 W0 to W508
Holding Bit Area H0 to H511 H0 to H508
Auxiliary Bit Area A0 to A959 A448 to A959 A0 to A956
Timer Area T0000 to T4095 T0000 to T4092
Counter Area C0000 to C4095 C0000 to C4092
DM Area D0 to D32767 D0 to D32764
Indirect DM addresses in
binary
@ D0 to @ D32767
Indirect DM addresses in
BCD
*D0 to *D32767
Constants ---
Data Registers ---
Index Registers ---
Indirect addressing using
Index Registers
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
A
15
AD+3
D+4
B
CD
08 07 00
BCD
Frame (order of data in line)
Stored from leftmost byte.
Note: A, B, C, and D represent bytes of data.
Data
area
