913
Display Instructions Section 3-25
ASCII
3-25-2 SEVEN-SEGMENT LED WORD DATA DISPLAY: SCH(047)
Purpose SCH(047) displays two user-specified digits on the 7-segment display on the
CPU Unit.
This instruction can be used in the CP1H CPU Units only. It cannot be used in
the CP1L CPU Units. If SCH(047) is used in a CP1L CPU Unit, Error Flag
(ER) will be turned ON.
Ladder Symbol
4D 41
54 45
52 49
41 4C
20 53
48 4F
52 54
MSG
MATERIAL SHORT
D107
D115
0.00
D100
M: D100
D101
D102
D103
D104
D105
D106
N
M
Spaces
16 characters × 2 lines max.
Reads ASCII
data up to 00.
Leave out spaces.
(Values ignored)
S
P
Four leftmost bits
Four rightmost bits
SCH(047)
S
C
S: Display source word
C: Control word (digit specification)
