917
Display Instructions Section 3-25
Example When W0.02 turns ON in the following example, the individual segments of
the 7-segment display on the CPU Unit will be controlled according to the con-
tents of D200 (7678 =“Ht”). The display remains even when W0.02 turns OFF.
When W0.03 turns ON, the display is cleared.
Numeric Values Corresponding to 7-segment Displays
Left digit Right digit
SCTRL(048)
D200
W0.02
D200
778
SCTRL(048)
#0000
W0.03
6
Display data
Display cleared.
"H" "t"
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 14
Bit 15
Bit
Status
15 14 13 10 09 08
0 1 0 1 1 0
7
6
12 11
11
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Bit 6
Bit 7
Bit
07 06 05 04 03 02 01 00
011110 0 0
Status
7
8
0 (3F) 1 (06) 2 (5B) 3 (4F) 4 (66) 5 (6D) 6 (7D) 7 (27) 8 (7F) 9 (6F)
A (77) B (7C) C (39) D (5E) E (79) F (71) G (3D) H (76) I (19 ) J (0D)
K (72) L (38) M (55) N (54) O (5C) P (73) Q (67) R (50) S (6D) T (78)
U (3E) V (1C) W (6A) X (1D) Y (6E) Z (49)
