948
Failure Diagnosis Instructions Section 3-28
The following table shows how to specify error codes and error details in S
and S+1.
Clearing FALS(007) Fatal System Errors
There are two ways to clear fatal system errors generated with FALS(007).
1. Turn the PLC OFF and then ON again.
2. When keeping the PLC ON, the system error must be cleared as if the
specified error had actually occurred.
Error name S S+1
Error code Error details
Memory Error 80F1 hex • Bits 00 to 09: Memory Error Location
Bit 00: User program
Bit 04: PLC Setup
Bit 07: Routing table
Bit 08: CPU Bus Unit Setup
Bit 09: Memory Cassette transfer error
• Bits 10 to 15: Invalid
I/O Bus Error 80C0 hex 0A0A hex: CPM1A Expansion Unit/Expansion I/O
Unit error
0000 hex: CJ-series Unit error (first Unit)
0001 hex: CJ-series Unit error (second Unit)
0F0F hex: CJ-series Unit error (unknown Unit)
0E0E hex: CJ-series Unit error (no End Cover)
Unit Number
Duplication
Error
80E9 hex CPU Bus Unit’s duplicated unit number
0000 to 000F hex
Special I/O Unit’s duplicated unit number
8000 to 805F hex
Too Many I/O
Points Error
80E1 hex Bits 13 to 15: Error Cause
Bits 00 to 12: Details
• Too many words for CPM1A Expansion Units/
Expansion I/O Units
Bits 13 to 15: 010
Bits 00 to 12: All zeroes
• Too many CPM1A Expansion Units/Expansion I/O
Units
Bits 13 to 15: 011
Bits 00 to 12: All zeroes
• Too many words for CJ-series Units
Bits 13 to 15: 111
Bits 00 to 12: All zeroes
I/O Table Setting
Error
80E0 hex --- (Not fixed.)
Program Error 80F0 hex • Bits 08 to 15: Error Cause
Bit 15: UM overflow error
Bit 14: Illegal instruction error
Bit 13: Differentiation overflow error
Bit 12: Task error
Bit 11: No END error
Bit 10: Illegal access error
Bit 09: Indirect DM BCD error
Bit 08: Instruction error
• Bits 00 to 07: Invalid
Cycle Time
Overrun Error
809F hex --- (Not fixed.)
