1.3How Setup Levels Are Configured and Operating the Keys on the Front Panel
E5GN
1–7
Ă• To move the mode at this level, simultaneously press the and
keys for at least three seconds in the operation level or adjustment level.
This level is for preventing unwanted or accidental modification of
parameters. Protected levels will not be displayed, and so the parameĆ
ters in that level cannot be modified.
Ă* The key pressing time can be changed in protect level move time".
Ă• This level is displayed when you turn the power ON. You can move to the
protect level, initial setting level and adjustment level from this level.
Ă• Normally, select this level during operation. During operation, the proĆ
cess value, set point and manipulated variable can be monitored, and the
alarm value and upperĆ and lowerĆlimit alarms can be monitored and
modified.
Ă• To move the mode at this level, press the key for less than one
second.
Ă• This level is for entering set values and offset values for control. This
level contains parameters for setting the AT (autoĆtuning), communicaĆ
tions writing enable/disable, hysteresis, multiĆSP, input shift values and
PID constants. You can move to the top parameter of the initial setting
level and operation level from here.
Ă• To move the mode at this level, press the key for at least three seconds
in the operation level or adjustment level or adjustment level. The PV disĆ
play flashes after one second.
Ă• This level is for specifying the input type, selecting the control method,
control period, setting direct/reverse action and alarm type. (When you
move to the operation level from the initial setting level, all items in the
display light.)
Ă• You can move to the advanced function setting level or communications
setting level from this level. To return to the operation level, press the
key for at least one second. To move to the communication setting
level, press the
key for less than one second.
Ă• To move the mode at this level, you must enter the password (Ć169") in
the initial setting level.
Ă• You can move to the calibration level only from this level.
Ă• This level is for setting the automatic return of display mode, MV limitĆ
ter, standby sequence, alarm hysteresis, ST (selfĆtuning) and for moving
to the user calibration level.
Ă• To move the mode at this level, press the
key for less than one second
in the initial setting level.
Ă• When the communications function is used, set the communications
conditions in this level. Communicating with a personal computer (host
computer) allows set points to be read and written, and manipulated
variables to be monitored.
NOTE This level is available only on the E5GNĆV03V .
F Protect level
F Operation level
F Adjustment level
F Initial setting
level
F Advanced
function setting
level
F Communications
setup level
