4–2
4.1 Shifting Input Values
Ă• The input shift type matched to the sensor currently selected in the
input type" parameter is displayed.
Ă• 2Ćpoint shift is applied only for nonĆcontact temperature sensors.
Ă• With 1Ćpoint shift, only the value set to the Temperature input shift"
parameter (adjustment level) is applied to the entire temperature input
range. For example, if the input shift value is set to 1.2_C", the process
value is treated as 201.2_C" after input shift is applied when the proĆ
cess value is 200_C.
Input
Temperature
Upper-limit
value
After shift
Input shift value
Before
shift
0
100
Lower-limit
value
In this example, let's shift the input of the K sensor by 1_C" by 1Ćpoint
input shift.
Operation level
(1) Press the key to move from the operation level" to the adjustĆ
ment level".
(2) Select the temperature input shift" parameter by pressing the
key.
(3) Press the or keys to set 1".
(4) To return to the operation level," press the key. The process
value 1_C larger than before shift is applied.
JShifting input
F 1-point shift
Tempera-
ture input
shift
Operation Procedure
Operation level
Adjustment level
Operation level
Temperature input
shift
