2 Basic Operations
2 - 18
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
This allows you to copy, switch, and clear scene data and scene group data.
It also allows you to perform test measurement and check the measurement results.
z
Status display area
This is the same as in the monitor window. Refer to Status display area on page 2-14.
z
Image display area
This is the same as in the monitor window. Refer to Image display area on page 2-15.
z
File selection section
Scene maintenance window
Button Description
Displays camera images. Selection is not possible when offline.
Displays logging images. Selection is not possible when offline.
Displays file images.
When online, displays images in the RAMDisk or external memory, i.e. USB mem-
ory.
When off-line, displays images in the following folder on the computer.
C:\Documents and Settings\<User name>\My Documents\OMRON FH
Launch the File Explorer and select an image file.
