Shortening the Measurement Takt Time
174
FQ2 User’s Manual
If you use partial input, perform teaching again. Partial input on the X axis is supported only by the FQ2-S3@-
@@@.
Changing the Image Input Mode
Pixel sampling can be applied to the input image to reduce image input time.
[Image] − [Camera setup] − − [Image input mode]
If you change the image input mode, perform teaching again.
• The minimum input widths are 16 for the X axis and 8 for the Y axis.
• The values of the monitor display positions are displayed for the coordinates in the measurement results.
• The coordinate values will not change as a result of the partial input settings.
Parameter Setting Description
Image Input
Mode
High-speed or Standard
Default for FQ2-S1 or FQ2-S2: High-speed, Default for
FQ2-S3: Standard
Pixel sampling can be applied to the input image to
reduce image input time.
Note
Important
Important
