Menu Tables
414
FQ2 User’s Manual
In/Out Tab Page
Calculation
Settings
Expression
[MENU]
Expression 0
to expression
31
Sets the number of the expression for
which to set a calculation.
--- Scene p. 157
Expression
settings
Sets the expressions. --- Scene
Data Uses the measurement result of other
items.
Inspection item, calculation symbols ( ( )
/ * . , + TJG)
Scene p. 162
Const. Inputs constants or mathematical opera-
tors.
0 to 9, ., calculation symbol ( ( ) / * ? , +
TJG)
Scene p. 157
Math. Uses functions in expressions. SIN, COS, ATAN, AND, OR, NOT, ABS,
MAX, MIN, MOD, SQRT, ANGL (angle of
straight line joining two points (center of
gravity and model center)), DIST (dis-
tance between two points), calculation
symbols ( ( ) / * . , + TJG)
Scene p. 159
Rename Deletes/copies the expression or
changes the expression name.
--- Scene p. 157
Copy --- Scene
Delete --- Scene
Judgement Specifies the parameters for judgement
of results.
Scene p. 161
Details
Output parameter
Reflect You can specify whether to reflect the
judgement results of a calculation in the
overall judgement.
No, Yes (default), Scene p. 161
Menu command Description Setting range Data Refer-
ence
Log setting
Statistical data Sets whether to record the number of
measurements and the number of NG
overall judgements.
ON (default) or OFF System p. 214
Image logging Sets the parameter to log measurement
image data.
All, Only NG, or None (default) System p. 209,
p. 214
Data log-
ging
Condition Sets the parameter to log measurement
data from inspection items.
All, Only NG, or None (default) System p. 209
Select data You can select the parameters to log
from the parameters in the filter items,
position compensation items, inspection
items and expression that are set.
Parameter names for the filter items,
position compensation items, inspection
items and expression that are set
System p. 209
Delete Log Resets the log data without turning OFF
the power supply.
--- System p. 216
Menu command Description Setting range Data Refer-
ence
