Menu Tables
FQ2 User’s Manual
413
Appendices
12
Inspection
Details
(Color Data)
Output parameter
Reflect You can specify whether to reflect the
judgement results of an inspection item
in the overall judgement.
No, Yes (default), Scene p. 138
(Area)
Meas. Parameter
Fill profile You can set how to process holes for an
Area inspection item.
None (default), Filling up holes, Fill Out-
line
Scene p. 144
Output parameter
Reflect You can specify whether to reflect the
judgement results of an inspection item
in the overall judgement.
No, Yes (default), Scene p. 142
Labeling
Meas. Parameter
Filling up
holes
Sets how to process areas surrounded
by the specified color.
Yes, No (default) Scene p. 150
Extract
Select this option if there are areas of the
specified color inside the measurement
region that you do not want to measure.
Yes, No (default) Scene p. 150
Extraction
condition
Scene p. 151
Number of
labels
Set the maximum number of labels to
detect.
Range: 1 to 100
Default: 100
Scene
Area Specify the area range to judge as a
label.
Range: 0 to 999,999,999.9999
Defaults: Upper limit: 999,999,999.9999,
Lower limit: 0
Scene
Gravity X Specify the gravity X position to judge as
a label.
Range: −99,999,999.9999 to
999,999,999.999
Defaults: Upper limit: 999,999,999.999,
Lower limit: ?999,999,999.9999
Scene
Gravity Y Specify the gravity Y position to judge as
a label.
Range: −999,999,999.9999 to
999,999,999.999
Defaults: Upper limit: 999,999,999.999,
Lower limit: −999,999,999.9999
Scene
Sorting
method
Set the condition to use for label number
reassignment.
Area ascending order, Area descending
order (default), Pos. X ascending order,
Pos. X descending order, Pos. Y ascend-
ing order, Pos. Y descending order
Scene p. 151
Output parameter
Reflect You can specify whether to reflect the
judgement results of an inspection item
in the overall judgement.
No, Yes (default), Scene p. 152
Menu command Description Setting range Data Refer-
ence
