External Reference Parameters
466
FQ2 User’s Manual
Color Data
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
312 Data logging switch for
area
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
700 Display
settings
Area display Setting/Acqui-
sition
0: Display area, 1: Do not dis-
play area
0 --- ---
701 Gravity X display Setting/Acqui-
sition
0: Display gravity X, 1: Do not
display gravity X
0 --- ---
702 Gravity Y display Setting/Acqui-
sition
0: Display gravity Y, 1: Do not
display gravity Y
0 --- ---
800 Area display pattern Setting/Acqui-
sition
0: Absolute value, 1: Relative
value, 2: Percentage
0 --- ---
801 Gravity X display pat-
tern
Setting/Acqui-
sition
0: Absolute value, 1: Relative
value
0 --- ---
802 Gravity Y display pat-
tern
Setting/Acqui-
sition
0: Absolute value, 1: Relative
value
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2JG ---
5 R average Acquisition
only
0 to 255 0 AR ---
6 G average Acquisition
only
0 to 255 0 AG ---
7 B average Acquisition
only
0 to 255 0 AB ---
8 Color difference Acquisition
only
0 to 442
The density average is dis-
played for a Monochrome Cam-
era.
0 AD Logged data
9 Color deviation Acquisition
only
0 to 221
The standard deviation of the
density is displayed for a Mono-
chrome Camera.
0DV---
103 Output
parame-
ter
Reflect Setting/Acqui-
sition
0: Yes, 1: No --- ---
124 Judge-
ment
condi-
tions
Color difference upper
limit
Setting/Acqui-
sition
0 to 442 442 --- Adjust judge-
ment
125 Color difference lower
limit
Setting/Acqui-
sition
0 to 442 0
External
reference
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
