External Reference Parameters
FQ2 User’s Manual
465
Appendices
12
127 Mea-
sure-
ment
condi-
tions
Background color Setting/Acqui-
sition
0: Black, 1: White, 2: Red, 3:
Green, or 4: Blue
0 --- ---
128 Fill profile Setting/Acqui-
sition
0: No, 1: Fill outline,
2: Filling up holes
0 --- ---
129 Area color inversion Setting/Acqui-
sition
0: None or 1: Enabled
The binary inversion is dis-
played for a Monochrome Cam-
era.
0 --- ---
135 Judge-
ment
Judgement upper limit
for area
Setting/Acqui-
sition
0 to 999,999,999.9999 999,999,
999.999
9
--- ---
136 Judgement lower limit
for area
Setting/Acqui-
sition
0 to 999,999,999.9999 0 --- ---
137 Judgement upper limit
for gravity X
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 99,999.9
999
--- ---
138 Judgement lower limit
for gravity X
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 −
99,999.9
999
--- ---
139 Judgement upper limit
for gravity Y
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 99,999.9
999
--- ---
140 Judgement lower limit
for gravity Y
Setting/Acqui-
sition
−99,999.9999 to 99,999.9999 −
99,999.9
999
--- ---
141 Judgement upper limit
for binary threshold
Setting/Acqui-
sition
0 to 255 255 --- ---
142 Judgement lower limit
for binary threshold
Setting/Acqui-
sition
0 to 255 0 --- ---
143 Mea-
sure-
ment
condi-
tions
Binary image display Setting/Acqui-
sition
(Monochrome Cameras)
0: No binary image display,
1: Binary image display
1 --- ---
144 Image type Setting/Acqui-
sition
0: Measurement image,
1: Color extraction image,
2: Selected color image,
3: Binary image after extraction
1 --- ---
145 Enable/disable multiple
selection
Setting/Acqui-
sition
0: Enabled,
1
: Disab
led
1 --- ---
160+N×10
(N=0 to 3)
Set color Registered color usage
flag N
Setting/Acqui-
sition
0: Not used, 1: Used 1(N=0),
0(N=1 to
3)
--- ---
161+N×10
(N=0 to 3)
Set color Registered color OR/
NOT flag N
Setting/Acqui-
sition
0: OR, 1: NOT 0 --- ---
162+N×10
(N=0 to 3)
Registered color maxi-
mum hue N
Setting/Acqui-
sition
0 to 359 359 --- ---
163+N×10
(N=0 to 3)
Registered color mini-
mum hue N
Setting/Acqui-
sition
0 to 359 0 --- ---
164+N×10
(N=0 to 3)
Registered color maxi-
mum saturation N
Setting/Acqui-
sition
0 to 255 255 --- ---
165+N×10
(N=0 to 3)
Registered color mini-
mum saturation N
Setting/Acqui-
sition
0 to 255 0 --- ---
166+N×10
(N=0 to 3)
Registered color maxi-
mum brightness N
Setting/Acqui-
sition
0 to 255 255 --- ---
167+N×10
(N=0 to 3)
Registered color mini-
mum brightness N
Setting/Acqui-
sition
0 to 255 0 --- ---
External
reference
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
