Sensor Data Units
Specifications
Table 1
*1: Do not allow the load current to exceed 50 mA. The output circuit may be damaged if the load current exceeds 50 mA.
Item Sensor Data Units
FQ-SDU1@ Parallel Interface Sensor Data Unit (SDU10: NPN, SDU15: PNP)
FQ-SDU2@ RS-232C Interface Sensor Data Unit (SDU20: NPN, SDU25: PNP)
I/O
specifi-
cations
Parallel I/O SDU1@ 11 inputs (TRIG, RESET, IN0 to IN7, and DSA)
24 outputs (GATE, D0 to D15, ACK, RUN, BUSY, OR, ERROR, STGOUT, and SHTOUT)
SDU2@ 8 inputs (IN0 to IN5, TRIG, and RESET)
7 outputs (ACK, RUN, BUSY, OR, ERROR, STGOUT, SHTOUT)
RS-232C 1 channel, 115,200 bps max.
*FQ-SDU2@ only.
Sensor interface FQ2-S3 connected with FQ-WU@@@): OMRON interface
*Number of connected Sensors: 1
Input specifications Refer to Table 2.
Output specifications
Rat-
ings
Power supply voltage 21.6 to 26.4 VDC (including ripple)
Insulation resistance Between all DC external terminals and case: 0.5 MΩ min. (at 250 VDC)
Current consumption 2.5 A max. (FQ2-S@@@@@@-@@@ + FQ-SDU@@)
0.4 A max. (FQ2-S3@-@@@ + FQ-SDU@@)
0.1 A max. (for FQ-SDU@@)
Envi-
ron-
mental
immu-
nity
Ambient temperature
range
Operating: 0 to 50°C, Storage: −20 to 65°C (with no icing or condensation)
Ambient humidity
range
Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere No corrosive gas
Vibration resistance
(destruction)
10 to 150 Hz, single amplitude: 0.35 mm, X/Y/Z directions, 8 min each, 10 times
Shock resistance
(destruction)
150 m/s
2
3 times each in 6 directions (up, down, right, left, forward, and backward)
Degree of protection IEC 60529 IP20
Materials Case: PC + ABS, PC
Size 62 × 90 × 65 (W×H×D) (Excluding connectors, DIN Track, and protrusions.)
Weight Approx. 150 g
Accessories Instruction Manual
Item NPN PNP
Input specifi-
cations
ON: Shorted to 0 V, or 1.5 V max.
OFF: Open (leakage current: 0.1 mA max.)
ON: Shorted to power supply voltage, or power supply volt-
age −1.5 V max.
OFF: Open (leakage current: 0.1 mA max.)
Output speci-
fications
*1
NPN open collector
30 VDC, 50 mA max., residual voltage: 1.2 V max.
PNP open collector
30 VDC, 50 mA max., residual voltage: 1.2 V max.
