Menu Tables
FQ2 User’s Manual
407
Appendices
12
Inspect Tab Page
Image adjustment
Basic
Teac h
for Two-edge Position Compensation, Two-edge Midpoint
Compensation, and Edge Rotation Position Compensation
Edge 0
region
Edge 1
region
Adjusts the size and position of the mea-
surement region, changes the measure-
ment direction, etc.
--- Scene ---
Edge 0 clr
ON/OFF
Edge 1 clr
ON/OFF
Sets whether to specify an edge color. ON or OFF (default) Scene ---
Set color. Specifies the color of the image for edge
detection (i.e., the border between the
measurement object and background).
R: 0 to 255
B: 0 to 255
G: 0 to 255
Scene ---
Color
palette
Displays a palette for color specification.
Edit Ref.
angle
(Edge Rota-
tion Position
Compensa-
tion only)
Set the reference angle. 0 to 180° (default:0) Scene ---
Judgement • Shape Search II Position Compensation Item and Search Position Compen-
sation Item
Almost the same as for the Search inspection item.
• Edge Position Compensation, Two-edge Position Compensation, Two-edge
Midpoint Compensation, and Edge Rotation Position Compensation
Almost the same as for the Edge Position inspection item.
Scene ---
Details
Meas. Parameter • Shape Search II Position Compensation Item and Search Position Compen-
sation Item
Almost the same settings as for the Search inspection item.
However, the [Sub-pixel] and [Multi-point output] settings of the Search
inspection item do not exist.
•
Edge Position Compensation, Two-edge Position Compensation, Two-edge Mid-
point Compensation, and Edge Rotation Position Compensation
The settings for the Edge Position Compensation item are almost the same
as those for the Edge Position inspection item.
Scene ---
Output parameter Scene ---
Scroll parameter
Source image You can select the image to which to
apply the results of position compensa-
tion processing.
Camera, Prev. (default) Scene p. 77
Interpolation You can select the precision of position
compensation.
Bilinear, None (default) Scene p. 77
Menu command Description Setting range Data Refer-
ence
Inspection
Item selected
Add item Used to add, modify, delete, copy, or
change the name of an inspection item.
Search, Shape Search II, Sensitive
Search, Edge Position, Edge Width,
Edge Pitch, Area, Color Data, Labeling
--- p. 93
Modify --- --- p. 94
Delete --- p. 94
Copy ---
Rename 15 alphanumeric characters ---
Menu command Description Setting range Data Refer-
ence
