Menu Tables
408
FQ2 User’s Manual
Inspection
Settings
Teach
for Search, Shape Search II. Sensitive Search
Model region Used to specify the region of the image
to register as the model with a combina-
tion of figures.
--- Scene p. 100,
p. 110,
p. 117
Add Rectangle, Ellipse, Wide circle, or Poly-
gon
Scene p. 100
Delete --- Scene
Copy --- Scene ---
Console --- Scene p. 101
OR/NOT OR (default) or NOT Scene p. 101
One/All One or All Scene ---
Insp. region Adjusts the size and position of the mea-
surement region.
--- Scene p. 102
Detection
point
You can specify which part of the model
to detect as coordinates during inspec-
tions.
--- Scene p. 102
for Edge Position, Edge Width, and Edge Pitch
Insp. region Adjusts the size and position of the mea-
surement region, changes the measure-
ment direction, etc.
--- Scene p. 125,
p. 129,
p. 133
Color ON/
OFF (for
Edge width
and Edge
position
Only)
Sets whether to specify an edge color. ON or OFF (default) Scene p. 124
Set color. Specifies the color of the image for edge
detection (i.e., the border between the
measurement object and background).
R: 0 to 255
B: 0 to 255
G: 0 to 255
Scene
Color pal-
ette
Displays a palette for color specification.
for Area, Labeling
Insp. region Adjusts the size and position of the mea-
surement region.
--- Scene p. 144,
p. 152
Set color The color for which to find the area is
specified.
--- Scene p. 142,
p. 148
Color pal-
ette
Displays a palette for color specification. Hue: 0 to 359, Saturation: 0 to 255
Brightness: 0 to 255
Exclusion: ON or OFF
Color inv.: Yes or No (default)
Scene
Display
Setting
Specifies the type of image to display on
the color specification display to check
on the image the color that was set for
the reference color.
Measurement Image, All Color Image
(default), Selected Color Image, or
Binary Image
Scene
Back-
ground
color
Specifies the background color of the
extracted image.
Black (default), white, red, green, or blue Scene
for Color Data
Insp. region Moves the measurement region or
adjusts the size of the measurement
region.
--- Scene p. 139
Menu command Description Setting range Data Refer-
ence
