Omron fq2

External Reference Parameters
438
FQ2 User’s Manual
Edge Position Compensation
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not
measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not per-
formed error,
−14: Figure not registered
error,
−15: Out of range error
−2 JG Logged data
5 Scroll X Acquisition
only
−99,999.9999 to
99,999.9999
0 DX Logged data
6 Scroll Y Acquisition
only
−99,999.9999 to
99,999.9999
0 DY Logged data
7 Edge position X Acquisition
only
−99,999.9999 to
99,999.9999
0 X Logged data
8 Edge position Y Acquisition
only
−99,999.9999 to
99,999.9999
0 Y Logged data
9 Standard position X Acquisition
only
−99,999.9999 to
99,999.9999
0 SX Logged data
10 Standard position Y Acquisition
only
−99,999.9999 to
99,999.9999
0 SY Logged data
103 Output
parame-
ter
Reflect Setting/Acqui-
sition
0: Yes, 1: No 0 --- ---
