External Reference Parameters
FQ2 User’s Manual
439
Appendices
12
120 Mea-
sure-
ment
condi-
tions
Position compensation
precision
Setting/Acqui-
sition
0: None, 1: Bilinear 0 --- ---
121 Setting method Setting/Acqui-
sition
0: Cancel position compen-
sation,
1: Position compensation
based on internal edge
position measurement
1 --- ---
122 Position compensation
Setting/Acqui-
sition
0: Camera image,
1: Previous image
0 --- ---
140 Set color Setting/Acqui-
sition
0: No edge color specifica-
tion,
1: Edge color specification
0 --- ---
141 Edge color red Setting/Acqui-
sition
0 to 255 255 --- ---
142 Edge color green Setting/Acqui-
sition
0 to 255 255 --- ---
143 Edge color blue Setting/Acqui-
sition
0 to 255 255 --- ---
147 Detection mode Setting/Acqui-
sition
0: Color IN, 1: Color OUT 0 --- ---
149 Edge level Setting/Acqui-
sition
0 to 100 50 --- ---
150 Noise level Setting/Acqui-
sition
0 to 442 5 --- ---
153 Monochrome density
change
Setting/Acqui-
sition
(Monochrome Cameras)
0: Light to Dark, 1: Dark to
Light
0 --- ---
157 Measurement method Setting/Acqui-
sition
(Monochrome Cameras)
0: Projection, 1: Differentia-
tion
0 --- ---
180 Judge-
ment
condi-
tions
Edge position X upper
limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
181 Edge position X lower
limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
182 Edge position Y upper
limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
183 Edge position Y lower
limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
184 Position compensation
X uppe
r li
mit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
185 Position compensation
X lower limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
186 Position compensation
Y upper limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
187 Position compensation
Y lower limit
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
